40T Industrial Closed Loop Cooling Tower 240000Kcal/h

Name: 40T Industrial Closed Loop Cooling Tower 240000Kcalh
Brand: Lanshuo
Price: 5500 USD

China 40T Industrial Closed Loop Cooling Tower 240000Kcal/h wholesale

Voltage : 380V/3-Phase/50Hz

Circulation pump power : 4kw

Warranty : 12 months

Material : Galvanized Steel Sheet / Stainless Steel Sheet

Application : cooling industrial machine

Fan power : 0.75kw, 2 sets

Cooling Capacity : 240000Kcal/h

Spray pump power : 1.5kw

Cooling Type : Counter Flow

Brand Name : Lanshuo

Model Number : LSN-40B

Certification : CE ISO

Place of Origin : China

MOQ : 1 set

Price : USD5500-6500 / set

Payment Terms : L/C,D/A,D/P,T/T,Western Union,MoneyGram

Supply Ability : 1000 sets per year

Delivery Time : 5-7 working days after receiving advanced payments

Packaging Details : plywood case / pallet

Type : Closed Type Cooling Tower

Contact Now

40T Industrial Closed Cooling Tower Counter Flow Water Cooling Tower

Product Specifications

Attribute	Value
Type	Closed Type Cooling Tower
Application	Cooling industrial machine
Cooling Type	Counter Flow
Material	Galvanized Steel Sheet / Stainless Steel Sheet
Voltage	380V/3-Phase/50Hz
Cooling Capacity	240000Kcal/h
Fan power	0.75kw, 2 sets
Spray pump power	1.5kw
Circulation pump power	4kw
Warranty	12 months

Industrial Cooling Tower Closed Water Cooling Tower

Main Features

Dual Cooling System: Combines water cooling and air cooling for optimal performance
Air Cooling: Stainless steel tubes absorb heat from circulating liquid, expelled by top-mounted fan
Water Cooling: Automatic spray system activates when temperatures exceed set points, creating evaporative cooling
Uses soft/purified water to extend equipment lifespan
Fully closed loop system prevents water loss, scaling, and blockages
Compact footprint requires no pond, saving space
Designed for continuous 24/7 operation

Product Overview

40T Industrial Closed Loop Cooling Tower 240000Kcal/h

Cooling towers efficiently remove heat absorbed in circulating cooling water systems for power plants, refineries, processing facilities, and more. Our 40T model handles substantial cooling demands while conserving water resources through closed-loop operation.

Technical Parameters

Model	LSN-40B
Water Cooling Capacity	240000kcal/h
Cooling Water Flow	40m³/h
Working Voltage	3-phase 380V, 50HZ
Water Outlet Diameter	DN75
Water Inlet Diameter	DN75
Water Replenishing Diameter	DN20
Drain Outlet Diameter	DN20
Fan (power of the generator)	0.75kw*2 sets
Spray Pump	1.5kw, 32m³/h flow
Circulating Pump	4kw, 32m lift, 25m³/h flow
Dimensions (LWH)	336012502580mm
Weight	910kg

Key Components

Coil: High-quality seamless stainless steel/copper pipes with galvanized coating for corrosion resistance (up to 32Mpa pressure rating)
Spray Pump: Premium rotary seal design for leak-free operation with high flow and low noise
Fan: Aluminum alloy axial-flow type
Casing: SS-304/316L or imported Aluminum-zinc alloy
Drift Eliminator: Removable PVC design ensures water loss below 0.005%
Cooling Tower Fill: 100% original PVC material with optimized cooling design

Packaging

Certifications

40T industrial cooling tower

closed loop cooling tower 240000Kcal/h

industrial cooling tower with warranty

40T Industrial Closed Loop Cooling Tower 240000Kcal/h Images
